Washtech PW1 Front Loading Warewasher, 500 x 600mm Rack
Front loading warewasher: W 720 × D 600 × H 750 mm chamber, 2, 4 and 6 minute cycles, holds up to 8 trays, 2.0 HP pump, three phase.
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Shipping & Delivery Information
Shipping & Delivery Information
Once your order has been processed and payment confirmed, we aim to dispatch your items within 1–3 business days. Please note we do not operate on weekends.
Delivery Schedule:
We deliver Monday to Friday during standard business hours only. Delivery times depend on both your location and the warehouse location of the product.
Estimated Delivery Times (after dispatch):
- Brisbane, Sydney, Melbourne (Metro): 2–5 business days
- Gold Coast, Sunshine Coast, Northern Rivers, Adelaide, Wollongong, Newcastle: 2–7 business days
- Perth, Hobart: 5–10 business days
- Other areas: 5–14 business days
Please be aware that while we work closely with our suppliers and couriers, delivery times are estimates and not guaranteed. Delays may occasionally occur due to warehousing backlogs or courier issues.
Warranty & Returns
Warranty & Returns
The warranty for each product is listed in the product description above.
If it’s not listed or you have any questions, please contact our customer support team.
Before placing your order, please take a moment to review the following:
- Warranty Information
- Returns & Exchanges Policy
These terms outline your rights and responsibilities regarding warranty coverage and product returns.
Detailed Summary
Detailed Summary
The Washtech PW1 is a front loading warewasher made in New Zealand by Washtech and distributed by Moffat. Its chamber, W 720 × D 600 × H 750 mm, takes pots, bowls and utensils, and an adjustable rail and tine bar holds up to 8 trays from 18 in to 1/1 GN. Hybrid controls run 2, 4 and 6 minute cycles, and a 2.0 HP wash pump uses 2.2 litres of water a cycle.
Key features and benefits
A front loader suits kitchens without room for a passthrough bench run: staff load from the front, like a large undercounter machine, but with a 750 mm high chamber for stockpots and mixing bowls. The rail and tine bar holds baking sheets and GN trays upright so the wash reaches both sides. A 2.0 HP wash pump drives independent stainless-steel wash and rinse arms, an assured rinse with booster pump keeps the final rinse consistent, and two-stage stainless-steel filtration and hands-free drainage make the end of the night quick.
Standard features
- Front loading chamber. W 720 × D 600 × H 750 mm.
- 2, 4 and 6 minute cycles. Match the cycle to the soil.
- Rail and tine bar. Holds up to 8 trays, 18 in to 1/1 GN.
- 2.0 HP wash pump. With dual chemical pumps.
- Hybrid controls. Easy change to higher power and rapid rinse recovery mode.
- Assured rinse. Including booster pump.
- Hands-free drainage. Sump and drain pump.
- Two-stage stainless-steel filtration. Wash and drain filters.
- Independent stainless-steel arms. Separate wash and rinse arms.
- Heavy-duty stainless-steel construction. With a stainless-steel manifold.
Best suited to
- Bakeries and patisseries. Trays, bowls and utensils.
- Restaurants. Pots and pans without a passthrough bench.
- Butchers and delis. Trays and containers through the day.
- Production kitchens. Large utensils between batches.
The PW1 has a heat recovery version, the PW1C, which needs no external canopy in most sites. For bins, crates and larger items, the PW2 has a chamber 1100 mm wide, and for a passthrough layout see the AL8. Smaller trays suit the undercounter TW. Before ordering, check the water supply temperature and pressure, the drain position and the power supply against the specification so the machine performs as rated from day one. Our team can help you size the machine to your covers and peak service, so you are not paying for capacity you will never use. If you are replacing an older warewasher, measure the existing water, drain and power positions so the installer knows what will need to move. Browse the Washtech range or call 1300 089 974.
Cleaning and maintenance
At the end of each shift, drain the machine through the hands-free drainage system, then lift out the stainless-steel wash and drain filters and rinse them. Check the wash and rinse arms for blocked jets, wipe the door seals, and leave the door open overnight so it can air. Keep both chemical containers topped up.
Installation, power and service
The PW1 is 835 mm wide, 780 mm deep and 1790 mm high, and weighs 164 kg. It needs hot water at 50–65 °C, 100–500 kPa and 10 L a minute through a ¾ in male connection, hose supplied; consumption is 2.2 L a cycle. Drainage is pumped through a 25 mm flexi-hose. Power is three phase 400–415 V at 15 A (10.5 kW) or 25 A (18 kW), and the connection kit has water, drain and chemical hoses but no plug or lead. The isolating switch must be within 1 m of the machine, not behind it. Washtech is backed by Moffat's 5-2-2 warranty and national service network; call 1300 089 974 to confirm the current terms.
Why buy from Hospitality Connect
Hospitality Connect has more than 20 years’ experience supplying and designing commercial kitchen solutions, with a showroom at Unit 7, 20 Hickeys Road, Penrith NSW 2750. You can view equipment in person and get advice from the team, Monday to Friday, 8:30 am to 4:30 pm. We deliver Australia-wide; equipment is kerbside with tailgate delivery as standard. SilverChef Rent-Try-Buy finance is available if you prefer to spread the cost. Call 1300 089 974.
Downloads
Specifications
Specifications
Frequently Asked Questions
What can the PW1 wash?
Pots, bowls, utensils and trays in a W 720 × D 600 × H 750 mm front loading chamber. The rail and tine bar holds up to 8 trays from 18 in to 1/1 GN.
How long are the cycles?
2, 4 and 6 minutes.
What water supply does it need?
Hot water at 50–65 °C, 100–500 kPa and 10 L a minute. It uses 2.2 litres a cycle.
What power does it need?
Three phase 400–415 V at 15 A (10.5 kW) or 25 A (18 kW). It is hard-wired, with no plug or lead supplied.
What is the difference between the PW1 and PW1C?
The PW1C adds an integrated heat recovery unit and touchscreen controls, runs on cold water, and needs no external canopy in most sites.
What is included?
Two 500 mm dish racks, a 500 mm cup rack, a cutlery container and a connection kit with water, drain and chemical hoses.
Does the PW1 need treated water?
Water quality affects results and machine life. The sheet sets limits of pH 7–8 and TDS up to 135, with maximums for chloride, sulphate, iron and chlorine; we can advise on a filter or softener if your supply is outside them.
