Blue Seal E514S-CB 600mm Electric Cooktop Sealed Hobs Cabinet Base
600 mm electric cooktop, cabinet base. Four sealed 2.6 kW cast-iron hot plates, 10.4 kW. 600 × 812 × 1085 mm incl. splashback.
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Shipping & Delivery Information
Shipping & Delivery Information
Once your order has been processed and payment confirmed, we aim to dispatch your items within 1–3 business days. Please note we do not operate on weekends.
Delivery Schedule:
We deliver Monday to Friday during standard business hours only. Delivery times depend on both your location and the warehouse location of the product.
Estimated Delivery Times (after dispatch):
- Brisbane, Sydney, Melbourne (Metro): 2–5 business days
- Gold Coast, Sunshine Coast, Northern Rivers, Adelaide, Wollongong, Newcastle: 2–7 business days
- Perth, Hobart: 5–10 business days
- Other areas: 5–14 business days
Please be aware that while we work closely with our suppliers and couriers, delivery times are estimates and not guaranteed. Delays may occasionally occur due to warehousing backlogs or courier issues.
Warranty & Returns
Warranty & Returns
The warranty for each product is listed in the product description above.
If it’s not listed or you have any questions, please contact our customer support team.
Before placing your order, please take a moment to review the following:
- Warranty Information
- Returns & Exchanges Policy
These terms outline your rights and responsibilities regarding warranty coverage and product returns.
Detailed Summary
Detailed Summary
The Blue Seal E514S-CB is a 600 mm electric cooktop with four sealed hot plates on a cabinet base, from the Evolution Series made by Moffat. Four 2.6 kW cast-iron plates, 10.4 kW in total, sit in a one-piece formed top, with a double-skin stainless cabinet below. It runs on a 400–415 V two-phase supply and stands 1085 mm high including the splashback.
Key features and benefits
The E514S-CB is a free-standing sealed-hob station with storage underneath. Four cast-iron plates give steady, even heat, each on a six-position switch with a power light and thermal protection. The formed one-piece top keeps spills in the hob wells. Below, the double-skin stainless cabinet keeps pans clean and can take an optional GN 1/1 racking kit. Front adjustable feet and rear rollers make levelling and cleaning behind the unit easier. The stainless exterior and vitreous enamelled control panel are built for daily commercial use.
Standard features
- Sealed hot plates. Four 2.6 kW cast-iron hot plate elements with thermal protection.
- Six-position switches. Each plate has a six-heat-position switch and its own power indicator light.
- One-piece worktop. Welded hob with a one-piece formed 2.0 mm 304 stainless-steel top and formed hob wells to contain spills.
- Heavy-duty build. 1.2 mm 304 stainless-steel side panels and splashback, vitreous enamelled control panel, aluminised internal construction.
- Control knobs. Large heat-resistant reinforced knobs with easy-view settings.
- Front access. Access to all parts from the front of the unit.
- Fully modular. Lines up with the Blue Seal Evolution Series at 812 mm deep.
- Cabinet base. Fully modular double-skin cabinet in 0.9 mm 304 stainless steel, inside and out, for a matched suite finish.
- Racking option. Optional GN 1/1 four-position racking kit.
- Legs and rollers. 63 mm heavy-duty 304 stainless-steel legs, with two adjustable feet at the front and two rollers at the rear.
Best suited to
- Cafes and small restaurants. Four plates with storage below.
- All-electric kitchens. Solid plates without gas.
- Tidy lines. Pans and supplies behind a stainless door.
- Matched suites. Lines up with other Evolution units at 812 mm deep.
The sealed-hob range also includes the E512S-B, E514S-B, E516S-B, E516S-LS, E516S-CB and E516S-RB. Cast-iron plates hold their temperature well once hot, so they suit steady pan work, stocks and long simmers rather than constant changes of heat. Before ordering, measure doorways and the delivery route against the packed size shown in the specifications. If you want an oven underneath, the 900 mm E506S and E56S ranges use the same six sealed plates. For faster response, compare the IN514 induction tops. All Evolution units are 812 mm deep so they line up in one suite. Have your electrician confirm the supply and circuit size before ordering. Browse the Blue Seal Evolution range or call 1300 089 974.
Cleaning and maintenance
The one-piece stainless-steel top has formed hob wells, so spills stay around the plates instead of running into the unit. Wipe the top down after service and keep the cast-iron plates dry and lightly seasoned to stop rust. All parts are reached from the front.
Installation, power and service
Allow a 600 mm wide, 812 mm deep space; the unit stands 1085 mm high including the splashback. It is hard-wired by a licensed electrician to a 400–415 V two-phase supply (2P+N+E) at 22 A; total load is 10.4 kW. Level it on the adjustable front feet; the rear rollers help when you move it to clean. No gas or water is needed. Net weight is 79 kg. Moffat supports Blue Seal through its national service network; ask us to confirm current warranty cover on 1300 089 974.
Why buy from Hospitality Connect
Hospitality Connect has more than 20 years’ experience supplying and designing commercial kitchen solutions, with a showroom at Unit 7, 20 Hickeys Road, Penrith NSW 2750. You can view equipment in person and get advice from the team, Monday to Friday, 8:30 am to 4:30 pm. We deliver Australia-wide; equipment is kerbside with tailgate delivery as standard. SilverChef Rent-Try-Buy finance is available if you prefer to spread the cost. Call 1300 089 974.
Downloads
Specifications
Specifications
Frequently Asked Questions
What power supply does the E514S-CB need?
10.4 kW on a 400–415 V two-phase supply (2P+N+E) at 22 A, hard-wired by a licensed electrician.
How are the hot plates controlled?
Each 2.6 kW cast-iron plate has a six-position switch, a power light and thermal protection.
What are sealed hobs?
Solid cast-iron hot plates set into a one-piece stainless top with formed wells, so spills are contained and the top is quick to clean.
What fits in the cabinet?
The double-skin cabinet takes an optional GN 1/1 four-position racking kit.
How heavy is it?
Net weight is 79 kg; it measures 600 × 812 × 1085 mm including the splashback.
