Washtech PW2C Wide Body Front Loading Warewasher with Heat Recovery Unit, 500mm Rack
Wide body front loading warewasher with heat recovery: W 1100 × D 650 × H 750 mm chamber, cold water, suits no canopy in most sites.
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Shipping & Delivery Information
Shipping & Delivery Information
Once your order has been processed and payment confirmed, we aim to dispatch your items within 1–3 business days. Please note we do not operate on weekends.
Delivery Schedule:
We deliver Monday to Friday during standard business hours only. Delivery times depend on both your location and the warehouse location of the product.
Estimated Delivery Times (after dispatch):
- Brisbane, Sydney, Melbourne (Metro): 2–5 business days
- Gold Coast, Sunshine Coast, Northern Rivers, Adelaide, Wollongong, Newcastle: 2–7 business days
- Perth, Hobart: 5–10 business days
- Other areas: 5–14 business days
Please be aware that while we work closely with our suppliers and couriers, delivery times are estimates and not guaranteed. Delays may occasionally occur due to warehousing backlogs or courier issues.
Warranty & Returns
Warranty & Returns
The warranty for each product is listed in the product description above.
If it’s not listed or you have any questions, please contact our customer support team.
Before placing your order, please take a moment to review the following:
- Warranty Information
- Returns & Exchanges Policy
These terms outline your rights and responsibilities regarding warranty coverage and product returns.
Detailed Summary
Detailed Summary
The Washtech PW2C is a wide body front loading warewasher with an integrated heat recovery unit, made in New Zealand by Washtech and distributed by Moffat. The heat recovery unit preheats the cold water supply, reducing steam emissions and energy use, and suits installation without an extraction canopy in many situations. The W 1100 × D 650 × H 750 mm chamber takes bins, crates and up to 20 trays.
Key features and benefits
The PW2C is the PW2 with heat recovery, for sites washing oversized items all day where steam and power costs add up. It is optimised for fast, efficient operation on cold inlet water, with a hot water line recommended only for faster initial heating. Longer 2.5, 4.5 and 6.5 minute cycles, a high powered dual-pump wash system and robust stainless-steel arms clean heavily soiled bins and crates, while a break tank and rinse pump cope with low inlet pressure. The counterbalanced, insulated split door opens the full chamber.
Standard features
- Integrated heat recovery unit. Preheats the cold water supply, reducing steam and energy use.
- Suits no extraction canopy. In many situations.
- Wide body chamber. Usable area W 1100 × D 650 × H 750 mm.
- 2.5, 4.5 and 6.5 minute cycles. On 4 litres of water a cycle.
- Upper rail with adjustable tines. Hangs ladles and whisks, or washes up to 20 baking or GN trays up to 40 mm deep.
- High powered dual-pump wash system. For heavily soiled items.
- Break tank and rinse pump fitted. Suits low inlet water temperature and/or pressure.
- Washtech hybrid controls. IP67 stainless switches with a customisable electronic timer.
- Stainless-steel wash and rinse arms. Precision stainless-steel jets.
- Double stainless-steel filtration. Dual scrap trays and a separate wash inlet filter.
- Watermark-approved backflow prevention. Atmospheric vacuum breaker.
- Easy installation. Water supply hose and detergent and rinse aid pumps with injector lines supplied.
- Counter-sprung split door. Insulated, for easy access to the chamber.
Best suited to
- Bakeries. Trays and bins with less steam.
- Supermarkets. Crates and tubs without new extraction.
- Hospitals and institutions. Large utensils with lower running costs.
- Production kitchens. Heavily soiled containers all day.
The PW2C is the heat recovery version of the PW2, with the same wide body chamber. For a passthrough layout with heat recovery, see the PW3C, and for a smaller front loader the PW1C. Before ordering, check the water supply temperature and pressure, the drain position and the power supply against the specification so the machine performs as rated from day one. Our team can help you size the machine to your covers and peak service, so you are not paying for capacity you will never use. If you are replacing an older warewasher, measure the existing water, drain and power positions so the installer knows what will need to move. Browse the Washtech range or call 1300 089 974.
Cleaning and maintenance
At the end of each shift, drain the tank, then lift out the dual scrap trays and the wash inlet filter and rinse them. Check the stainless-steel wash and rinse arms for blocked jets, wipe the door seals, keep the heat recovery unit clear, and leave the door open overnight so the chamber can air. Keep the detergent and rinse aid containers topped up.
Installation, power and service
The PW2C is 1235 mm wide, 860 mm deep and 2065 mm high (2165–2225 mm door open), and weighs 260 kg. It needs potable cold water under 25 °C at 100–350 kPa and 10 L a minute through a ¾ in male connection, using 4 L a cycle; a 65 °C fill-only hot line speeds initial heating and can be replaced by a second cold line. Waste is 1.5 in BSP male to a 50 mm minimum line. Power is three phase 400 V at 30 A (19.5 kW) or 20 A (12 kW). Washtech is backed by Moffat's warranty and national service network; call 1300 089 974 to confirm the current terms.
Why buy from Hospitality Connect
Hospitality Connect has more than 20 years’ experience supplying and designing commercial kitchen solutions, with a showroom at Unit 7, 20 Hickeys Road, Penrith NSW 2750. You can view equipment in person and get advice from the team, Monday to Friday, 8:30 am to 4:30 pm. We deliver Australia-wide; equipment is kerbside with tailgate delivery as standard. SilverChef Rent-Try-Buy finance is available if you prefer to spread the cost. Call 1300 089 974.
Downloads
Specifications
Specifications
Frequently Asked Questions
Does the PW2C need an extraction canopy?
It is suitable for installation without an extraction canopy in most instances. Full certification is available on request.
What water supply does it need?
Cold water under 25 °C at 100–350 kPa and 10 L a minute. A 65 °C hot water line for fill only is recommended for faster initial heating, or it can be another cold line.
How long are the cycles?
2.5, 4.5 and 6.5 minutes, using 4 litres of water a cycle.
How many trays a cycle?
Up to 20 baking or GN trays up to 40 mm deep, on the internal upper rail with adjustable tines.
What power does the PW2C need?
Three phase 400 V at 30 A (19.5 kW) or 20 A (12 kW).
What drain does it need?
A 1.5 in BSP male connection to a drain line of at least 2.0 in (50 mm).
Does the PW2C need treated water?
Water quality affects results and machine life. The sheet sets limits of pH 7–8 and TDS up to 135, with maximums for chloride, sulphate, iron and chlorine; we can advise on a filter or softener if your supply is outside them.
