FED-X Chef Base Refrigerated Drawer Bench 184L XCB-36
Hurry up, only 3 items left in stock.
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Shipping & Delivery Information
Shipping & Delivery Information
Once your order has been processed and payment confirmed, we aim to dispatch your items within 1–3 business days. Please note we do not operate on weekends.
Delivery Schedule:
We deliver Monday to Friday during standard business hours only. Delivery times depend on both your location and the warehouse location of the product.
Estimated Delivery Times (after dispatch):
- Brisbane, Sydney, Melbourne (Metro): 2–5 business days
- Gold Coast, Sunshine Coast, Northern Rivers, Adelaide, Wollongong, Newcastle: 2–7 business days
- Perth, Hobart: 5–10 business days
- Other areas: 5–14 business days
Please be aware that while we work closely with our suppliers and couriers, delivery times are estimates and not guaranteed. Delays may occasionally occur due to warehousing backlogs or courier issues.
Warranty & Returns
Warranty & Returns
The warranty for each product is listed in the product description above.
If it’s not listed or you have any questions, please contact our customer support team.
Before placing your order, please take a moment to review the following:
- Warranty Information
- Returns & Exchanges Policy
These terms outline your rights and responsibilities regarding warranty coverage and product returns.
Detailed Summary
Detailed Summary
The FED-X XCB-36 Chef Base Refrigerated Drawer Bench 184L is designed for busy commercial kitchens and prep lines. It offers 184 L gross volume (162 L net) and holds -1 to +5°C at up to 32°C, 65%RH ambient. The stainless steel unit measures 924 x 816 x 658 mm with 2 hinged doors. It runs on 240V, 396W/10A and uses 3.241 kWh/24h. Warranty cover is 2 years parts and labour plus 2 years parts only when products registered within 14 days of invoice.
Key Features
- Gross Volume: 184L
- Net Volume: 162L
- Max Ambient Temperature: 32°C, 65%RH
- Temperature Range: -1 to +5°C
- Stainless steel interior and exterior with rounded corners for easy cleaning
- 60 mm HFCs and CCFC-freefoam body insulation
- Tropicalised for Australian conditions
- User-friendly digital controls
- Rapid recovery rate
- Fan-forced evaporator cooling
- Heavy-duty castors with front-wheel brakes
- Austrian Fulterer door runners for smooth, reliable operation with durability
- Equipped with two drawers to hold cold ingredients, compatible with gastronomy Pan (sold separately) in various configurations
- Each drawer gasket is removable for easy cleaning and maintenance
- Raised Edge Top & Removable Magnetic Drawer Gaskets (GN pan is required for using this unit)
- Certified 4M1 food-safe with a 3 Star GEMS rating
- Drawers: 2
- Depth: 530mm
- Pan (height): 100mm
Specifications
| Model | XCB-36 |
|---|---|
| Body | Stainless Steel |
| Doors | 2 |
| Door Type | Hinged Doors |
| Gross Volume | 184 L |
| Net Volume | 162 L |
| Temperature Range | -1 to +5°C |
| Max Ambient Temperature | 32°C, 65%RH |
| Power | 240V, 396W/10A |
| Energy Consumption | 3.241 kWh/24h |
| Width | 924 mm |
| Depth | 816 mm |
| Height | 658 mm |
| Net Weight | 85 kg |
| Packed Dimensions (W x D x H) | 886 x 990 x 724 mm |
| Warranty | 2 Years Parts & Labour Plus 2 Years Parts Only Warranty When Products Registered Within 14 Days Of Invoice |
Specifications
Specifications
Frequently Asked Questions
What temperature does the XCB-36 hold?
The XCB-36 operates at -1 to +5°C, rated for ambient conditions up to 32°C, 65%RH.
What are the dimensions of the XCB-36?
It measures 924 mm wide x 816 mm deep x 658 mm high and weighs 85 kg net.
What is the capacity of the XCB-36?
The XCB-36 has a gross volume of 184 L and a net volume of 162 L.
What power supply does the XCB-36 need?
The XCB-36 is rated at 240V, 396W/10A. Energy consumption is 3.241 kWh/24h.
What warranty comes with the XCB-36?
FED-X covers the XCB-36 with 2 Years Parts & Labour Plus 2 Years Parts Only Warranty When Products Registered Within 14 Days Of Invoice.
What is the XCB-36 made from?
The cabinet body is stainless steel.
